DATA SHEET

G6K-2P-DC5

Omron Electronics

Signal Relay 5VDC 1A DPDT(10x6.5x5)mm THT .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6K-2P-DC5
RoHS:
Yes
HTS:
8536490050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
10 x 6.5 x 5 mm
Termination Style:
PC Pin
Coil Current:
21.1 mA
Contact Form:
2 Form C
The G6K-2P DC5 is a Subminiature Relay with DC coil. This G6K-series surface mount subminiature relay has 2CO (DPDT) Ag contact with PCB terminals. Consumes approximately 70% the power of a conventional OMRON model and operates at a current that is as low as 100mW. Surface mounting terminal models incorporate a unique terminal structure with high infrared irradiation efficiency which allows the terminal temperature to rise easily when mounting the IRS, thus ensuring excellent soldering. Single side stable function Fully sealed enclosure Low profile of 5.2mm improves mounting efficiency -40 to 70°C Operating temperature range Applications Industrial, Communications & Networking, Test & Measurement, Security, Automation & Process Control, Consumer Electronics, Building Automation
Search Keywords:
G6K2PDC5
IN STOCK: 5,273
Ships today, if you order in
Manufacturer Stock:
12,000   can ship 12/6/24
Minimum Order:
10
Factory Lead-Time
4 Weeks can ship 12/19/24
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$3.13
$31.300
50
$2.53
$126.500
250
$2.42
$605.000
500
$2.37
$1,185.000
1,000
$2.32
$2,320.000
2,500
$2.28
$5,700.000
5,000
$2.23
$11,150.000
7,500 +
$2.20
$16,500.000
