G7L-2A-BUBJ-CB-AC100/120
Omron ElectronicsPower relay ideally suited for high inrush fluid pump control .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G7L-2A-BUBJ-CB-AC100/120
RoHS:
Yes
HTS:
8536490075
COO:
ID
ECCN:
EAR99
Package Type:
Relay Construction:
Non-Latching
AC Coil Voltage:
100,120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPST-NO
Maximum Current Rating:
25 A
Mounting:
Bracket Mount
Termination Style:
Screw Terminal
Push to Test Button:
Yes
Led Indicator:
No
Operating Temperature:
-25 to 60 °C
The G7L-2A-BUB-J-CB-AC100/120 is a 2-pole general-purpose Power Relay with AC coil, G7D series. DPST-NO contact configuration, screw terminals, upper bracket mounting. With test button. High-capacity, high-withstand voltage relay with no contact chattering for momentary voltage drops up to 50% of rated voltage. Miniature size for maximum switching capacity, particularly for inductive loads. Wide-range AC-activated coil that handles 100 to 120VAC or 200 to 240VAC at either 50 or 60 Hz. UL Class B construction standard.
Safety design with contact gap of 3mm
UL94V-0 Flame resistant
Upper bracket mount
With test button
Applications
Industrial, Power Management, Automation & Process Control, Motor Drive & Control
Search Keywords:
G7L2ABUBJCBAC100120
IN STOCK:
1,831
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
11 Weeks
Quantity
Unit Price
Ext. Price
5
$16.32
$81.600
20
$15.85
$317.000
40
$15.33
$613.200
60
$15.09
$905.400
100
$14.85
$1,485.000
260
$14.14
$3,676.400
500
+
$13.92
$6,960.000
