SS-10 by omron electronics
DATA SHEET

SS-10

Omron Electronics

Switch Snap Action N.O./N.C. SPDT Pin Plunger 10.1A 250VAC 1.47N Screw Mount Solder .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
SS-10
Alias/AKA:
SS10BYOMI
RoHS:
Yes
HTS:
8536509040
COO:
ID
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Pin Plunger
Contact Rating @ Voltage:
10.1@250VAC 14VDC A
Maximum Movement Differential:
0.12 mm
Operating Force:
1.47 N
Termination Style:
Solder
Dimension:
19.8 x 6.4 x 15.4 mm
Body Orientation:
Straight
IP Rating:
IP40
The OMRON ELECTRONICS SS-10 is a reliable and versatile switch perfect for a wide range of applications. With its snap action mechanism, this switch provides excellent performance and durability. It features a single pole double throw (SPDT) configuration, allowing for both normally open (N.O.) and normally closed (N.C.) contacts. The pin plunger design ensures precise and efficient actuation with a 1.47N force. This switch can handle a maximum current of 10.1A and a maximum voltage of 250VAC, making it suitable for demanding electrical circuits. Its screw mount and solder terminals provide convenient and secure installation options. Choose the OMRON ELECTRONICS SS-10 for your next project and experience reliable and efficient switching performance.
Search Keywords:
SS10
IN STOCK: 135
Ships today, if you order in
On Order:
6,000   can ship 11/25/24
Minimum Order:
10
Factory Lead-Time
4 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$1.515
$15.150
100
$1.031
$103.100
250
$1.015
$253.750
500
$1.000
$500.000
1,000
$0.985
$985.000
2,500
$0.970
$2,425.000
5,000
$0.956
$4,780.000
7,500 +
$0.941
$7,057.500
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
