V-10G3-1C24-K
Omron ElectronicsSwitch Snap Action N.O./N.C. SPDT Long Hinge Lever Quick Connect 10A 250VAC 250VDC 248.57VA 0.34N Screw Mount .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
V-10G3-1C24-K
Alias/AKA:
V10G31C24KBYOMI
RoHS:
Yes
HTS:
8536509040
COO:
ID
ECCN:
EAR99
Supplier Standard Pack
100
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Stainless Steel/Long Hinge Lever
Contact Rating @ Voltage:
248.57@(CSA/UL) A
Maximum Movement Differential:
2 mm
Operating Force:
0.34 N
Termination Style:
Quick Connect
Dimension:
72.2 x 10.3 x 28.5 mm
Body Orientation:
Straight
IP Rating:
IP40
The V-10G3-1C24-K is a single-pole double-throw (SPDT) general purpose Snap Action Switch with quick-connect terminals, a long hinge lever actuator and 0.5mm (G gap) contact gap. It is widely used for applications where long life expectancy and high reliability is required.
Silver alloy contacts
2.9mm Mounting hole size
100MΩ at 500VDC Minimum insulation resistance
15mΩ Maximum contact resistance
IP40 Protection rating
Applications
Industrial
Search Keywords:
V10G31C24K
IN STOCK:
5,607
Can Ship immediately
Minimum Order:
10
Factory Lead-Time
4 Weeks
Quantity
Unit Price
Ext. Price
10
$2.26
$22.600
50
$1.52
$76.000
300
$1.50
$450.000
500
$1.48
$740.000
1,000
$1.45
$1,450.000
2,500
$1.43
$3,575.000
5,000
$1.41
$7,050.000
7,500
+
$1.39
$10,425.000
