XF2M-5015-1A by omron electronics
DATA SHEET

XF2M-5015-1A

Omron Electronics

50 Position FPC Connector Contacts, Top and Bottom 0.020" (0.50mm) Surface Mount, Right Angle .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
XF2M-5015-1A
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1500
Package Type:
Type:
FPC Connector
Number of Contacts:
50
Pitch:
0.5 mm
Mounting:
Surface Mount
Termination Method:
Solder
Maximum Voltage Rating:
50,50 VDC|VAC
Maximum Current Rating:
0.5 A
Dimension:
29.1mm x 6.2mm x 2.1 mm
Operating Temperature:
-30 to 85 °C
0.5mm Pitch Rotary Backlock Low Profile Connectors - XF2M Series 0.5mm pitch FPC connectors with a 2mm on board profile and double-sided contacts. These 0.5mm pitch connectors have a rotary backlock mechanism which aids FPC mounting and provides improved contact reliability, easy operation during assembly and secure mounting in tight spaces. These low profile 0.5mm pitch FPC connectors have LCP resin (UL94V-0) housings and sliders. Suitable applications for these low profile 0.5mm FPC connectors include small mobile devices such as digital cameras, mobile phones, digital audio and video players, DVD players and digital video cameras. Rotary backlock mechanism to ensure secure connection Low 2mm on-board profile Side entry SMT terminals 0.3mm applicable FPC thickness Single row double sided contacts Halogen free
Search Keywords:
XF2M50151A
IN STOCK: 1,405
Can Ship immediately
Minimum Order:
10
Factory Lead-Time
4 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$2.09
$20.900
100
$1.59
$159.000
250
$1.56
$390.000
500
$1.54
$770.000
1,500
$1.51
$2,265.000
3,000
$1.49
$4,470.000
6,000
$1.47
$8,820.000
7,500 +
$1.45
$10,875.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
