AGN200S12 by panasonic electronic components
DATA SHEET

AGN200S12

Panasonic Electronic Components

Signal Relay 12VDC 1.028KOhm 1A DPDT(10.6mm 5.7mm 10mm) SMD General Purpose Relay .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AGN200S12
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tube
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
1 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
10.6 x 5.7 x 10 mm
Termination Style:
Gull Wing
Coil Current:
11.7 mA
Contact Form:
2 Form C
The PANASONIC EW/AROMAT part AGN200S12 is a compact and highly versatile signal relay suitable for a wide range of applications. This relay operates at 12VDC and has a resistance of 1.028KOhm, making it highly efficient and reliable. With a maximum current capacity of 1A, it can handle a variety of electrical loads with ease. Featuring a double-pole, double-throw (DPDT) configuration, this relay provides excellent switching capabilities and allows for flexible circuit connections. Its small dimensions of 10.6mm x 5.7mm x 10mm (length x width x height) make it ideal for space-constrained environments or PCB designs. Designed for surface-mount technology (SMD) applications, this general purpose relay from PANASONIC EW/AROMAT offers excellent performance and durability. It is a dependable choice for various industries including automotive, telecommunications, consumer electronics, and industrial automation.
Search Keywords:
AGN200S12
  Different packaging options available.  See Alternatives
IN STOCK: 2,350
Can Ship immediately
Minimum Order:
50
Multiple:
50
Factory Lead-Time
20 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
50
$1.105
$55.250
250
$1.049
$262.250
500
$1.024
$512.000
1,000
$1.005
$1,005.000
2,500
$0.995
$2,487.500
5,000
$0.985
$4,925.000
7,500
$0.975
$7,312.500
10,000 +
$0.965
$9,650.000
Suppliers Standard Package
