DATA SHEET

AQS225R2S

Panasonic Electronic Components

Solid State Relay 50mA 1.5V DC-IN 0.07A 80V AC/DC-OUT 16-Pin SOP Tube .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQS225R2S
RoHS:
Yes
HTS:
8541408000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Tube
Output Type:
AC,DC
Maximum Output Voltage:
80 V
Maximum Output Current:
0.07 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Surface Mount
Circuit Arrangement:
4 Form A
Dimension:
10.37 x 4.4 x 2.1 mm
The PANASONIC EW/AROMAT part AQS225R2S is a solid state relay with a compact 16-pin SOP (Small Outline Package) design. It features a low input current of 50mA and operates at a low input voltage of 1.5V DC. With an output current of 0.07A and a maximum output voltage of 80V AC/DC, this solid state relay provides efficient and reliable switching performance. The AQS225R2S is an ideal component for applications requiring precise control and protection in various electrical systems. It comes packaged in a tube for convenient storage and handling.
Search Keywords:
AQS225R2S
  Different packaging options available.  See Alternatives
IN STOCK: 4,774
Can Ship immediately
Factory Lead-Time
16 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$21.44
$21.440
10
$16.77
$167.700
25
$15.79
$394.750
50
$14.87
$743.500
100
$14.09
$1,409.000
250
$12.97
$3,242.500
500 +
$12.14
$6,070.000
Tools/3D Models
