AV402461 by panasonic electronic components
DATA SHEET

AV402461

Panasonic Electronic Components

Switch Snap Action N.O./N.C. SPDT Hinge Lever Solder 0.1A 30VDC 0.25N Screw Mount .. see full description

RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AV402461
RoHS:
Yes
HTS:
8536507000
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
BOX
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Hinge Lever
Contact Rating @ Voltage:
0.1@30VDC A
Maximum Movement Differential:
0.7 mm
Operating Force:
0.25 N
Termination Style:
Solder
Dimension:
7.5 x 2.5 x 13.6 mm
Body Orientation:
Straight
IP Rating:
N/A
The PANASONIC EW/AROMAT part AV402461 is a versatile switch designed for various applications. It features a snap action mechanism, allowing for quick and reliable operation. The switch is a single-pole double-throw (SPDT) type, which means it can either be normally open or normally closed, giving you flexibility to suit your needs. The hinge lever design ensures smooth and precise actuation, making it ideal for precise control. With a solder connection, it provides a secure and durable electrical connection. The switch can handle up to 0.1A and 30VDC, making it suitable for low voltage applications. It also features a 0.25N actuation force, providing a satisfying tactile feedback. The switch can be easily mounted using screws, ensuring stability in your application. Overall, the PANASONIC EW/AROMAT AV402461 is a reliable and versatile switch that delivers precise control and durability.
Search Keywords:
AV402461
IN STOCK: 1,280
Ships today, if you order in
Minimum Order:
10
Factory Lead-Time
15 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$2.29
$22.900
100
$1.59
$159.000
250
$1.49
$372.500
500
$1.39
$695.000
1,000
$1.30
$1,300.000
2,500
$1.28
$3,200.000
5,000
$1.21
$6,050.000
7,500 +
$1.19
$8,925.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
