CB1AH-P-24V by panasonic electronic components
DATA SHEET

CB1AH-P-24V

Panasonic Electronic Components

Relays 24VDC 411Ohm 20A SPST-NO(26mm 22mm 26mm) THT Automotive Relay Automotive .. see full description

RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1AH-P-24V
RoHS:
Yes
HTS:
8536410020
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
BOX
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
20A
Coil Voltage:
24 VDC
Coil Current:
58 mA
Coil Resistance:
411 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
14 VDC
Must Release Voltage:
8.4 VDC
Operate Time:
15 ms
Seal:
Sealed
Mounting:
Through Hole
Termination Style:
PC Pin
Dimension:
26 x 22 x 26 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton
The PANASONIC EW/AROMAT part CB1AH-P-24V is a high-quality automotive relay designed for use in various electronic systems. With a 24VDC operating voltage, 411Ohm coil resistance, and a SPST-NO configuration, this relay can handle up to 20A of current. Its compact dimensions (26mm x 22mm x 26mm) make it suitable for installation in tight spaces within vehicles. Trust this reliable relay to effectively control power circuits in automotive applications.
Search Keywords:
CB1AHP24V
IN STOCK: 276
Ships today, if you order in
On Order:
1,000   can ship 2/19/25
Minimum Order:
50
Multiple:
50
Factory Lead-Time
24 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
50
$3.09
$154.500
100
$2.50
$250.000
250
$2.14
$535.000
500
$2.10
$1,050.000
1,000
$2.06
$2,060.000
2,500
$2.02
$5,050.000
5,000
$1.98
$9,900.000
7,500 +
$1.95
$14,625.000
