SP4-P-DC24V by panasonic electronic components
DATA SHEET

SP4-P-DC24V

Panasonic Electronic Components

Power Relay 24VDC 10A 4PDT(51x25.6x22)mm THT .. see full description

RoHS Compliant
BOX Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
SP4-P-DC24V
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Package Type:
BOX
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
4PDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-50 to 60 °C
Coil Resistance:
1.92 KOhm
The PANASONIC EW/AROMAT SP4-P-DC24V is a high-quality power relay designed to deliver reliable performance in various applications. This 4PDT (4 pole, double throw) relay operates on a 24VDC power supply and has a maximum contact rating of 10A. With compact dimensions measuring 51mm x 25.6mm x 22mm, it can be easily integrated into space-constrained designs. The Through-Hole Technology (THT) construction ensures secure and stable connections. This power relay is a versatile solution for tasks that require robust switching capabilities and efficient energy management.
Search Keywords:
SP4PDC24V
IN STOCK: 209
Can Ship immediately
On Order:
300   can ship 3/12/25
Factory Lead-Time
22 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$30.85
$30.850
5
$26.35
$131.750
30
$25.34
$760.200
50
$23.00
$1,150.000
100
$22.56
$2,256.000
250
$22.11
$5,527.500
500 +
$21.78
$10,890.000
