TQ2SA-5V-X by panasonic electronic components
DATA SHEET

TQ2SA-5V-X

Panasonic Electronic Components

Signal Relay 5VDC 2A DPDT(14x11.5x5.6)mm SMD .. see full description

RoHS Compliant
Reel Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TQ2SA-5V-X
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Reel
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Surface Mount12526
Operating Temperature:
-40 to 85 °C
Dimension:
14 x 11.5 x 5.6 mm
Termination Style:
Gull Wing12536
Coil Current:
28.1 mA
Contact Form:
2 Form C12515
The PANASONIC EW/AROMAT part TQ2SA-5V-X is a high-quality signal relay designed for various electronic applications. This relay operates at 5VDC with a maximum current rating of 2A, making it perfect for handling low to medium-power signals. Featuring a Double Pole Double Throw (DPDT) configuration, this compact SMD (14x11.5x5.6mm) relay is suitable for use in space-constrained designs. Its surface mount design allows for easy installation and integration onto PCBs.With its reliable performance and robust construction, the TQ2SA-5V-X ensures efficient and stable signal transmission, making it ideal for applications such as telecommunication systems, industrial controls, audio equipment, and more.
Search Keywords:
TQ2SA5VX
  Different packaging options available.  See Alternatives
  Possible Replacement options available.  See Alternatives
IN STOCK: 2,000
Can Ship immediately
Minimum Order:
500
Multiple:
500
Factory Lead-Time
40 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
500
$1.34
$670.000
1,000
$1.31
$1,310.000
2,500
$1.28
$3,200.000
5,000
$1.26
$6,300.000
7,500
$1.23
$9,225.000
10,000
$1.21
$12,100.000
15,000
$1.19
$17,850.000
25,000 +
$1.17
$29,250.000
