1700037 by phoenix contact
DATA SHEET

1700037

Phoenix Contact

PCB terminal block - nominal current: 24 A - rated voltage (III/2): 400 V - nominal cross section: 2.5 mm² - pitch: 5 mm - number of positions: 1 - connection method: Front screw connection - mounting: Wave soldering - conductor/PCB connection direction: 90 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm. The article can be aligned to create different nos. of positions! .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1700037
Alias/AKA:
FRONT 2 5-V/SA 5
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
N/R
Number of Circuits:
1
Maximum Voltage Rating:
400 V
Maximum Current Rating:
24 A
Wire Size:
14-24 AWG
Operating Temperature:
-25 to 80 °C
The PHOENIX CONTACT part 1700037 is a PCB terminal block that is designed for reliable and safe electrical connections. It has a nominal current rating of 24 A and a rated voltage of 400 V (III/2). The terminal block has a nominal cross section of 2.5 mm² and a pitch of 5 mm. With its front screw connection method, it ensures a secure and stable connection. The mounting method is wave soldering, making it easy to integrate into PCB assemblies. The conductor/PCB connection direction is 90°, allowing for flexibility in the design and layout of the PCB. The terminal block is in a vibrant green color and has a linear pinning pin layout. Additionally, the solder pin has a length of 3.5 mm. This article can be aligned to create different numbers of positions to suit specific requirements.
Search Keywords:
1700037
IN STOCK: 0
On Order:
2,000   can ship 12/23/24
Minimum Order:
50
Multiple:
50
Factory Lead-Time
9 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
50
$2.03
$101.500
250
$1.80
$450.000
500
$1.73
$865.000
1,000
$1.68
$1,680.000
2,500
$1.64
$4,100.000
5,000
$1.61
$8,050.000
7,500
$1.59
$11,925.000
10,000 +
$1.57
$15,700.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
