DATA SHEET

1715035

Phoenix Contact

PCB terminal block - nominal current: 17.5 A - rated voltage (III/2): 400 V - nominal cross section: 1.5 mm² - pitch: 5 mm - number of positions: 3 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.5 mm. The article can be aligned to create different nos. of positions! .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1715035
Alias/AKA:
MKDS 1 5/ 3
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:
250
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
5 mm
Number of Circuits:
3
Maximum Voltage Rating:
400 V
Maximum Current Rating:
17.5 A
Wire Size:
14-26 AWG
Operating Temperature:
N/A
The PHOENIX CONTACT part 1715035 is a high-quality PCB terminal block designed for efficient and reliable electrical connections. With a nominal current rating of 17.5 A and a rated voltage of 400 V, this terminal block is perfect for a wide range of applications. It features a 1.5 mm² nominal cross section and a 5 mm pitch, making it easy to connect various wire sizes. The terminal block utilizes a screw connection with tension sleeve for secure and stable connections. It is designed for wave soldering mounting, ensuring convenient and efficient installation on PCBs. The conductor/PCB connection direction is 0°, allowing for easy alignment and consistent connections. In terms of aesthetics, the terminal block is available in a vibrant green color, making it easily identifiable on the PCB. The pin layout is linear, allowing for organized and streamlined connections. The solder pin measures 3.5 mm, providing ample space for soldering and ensuring a strong bond.One of the key advantages of this terminal block is its flexibility. The article can be aligned to create different numbers of positions, accommodating various application requirements. This ensures that the terminal block can be easily customized to suit the needs of the project at hand. Overall, the PHOENIX CONTACT part 1715035 is an excellent choice for anyone seeking a reliable, versatile, and efficient PCB terminal block solution.
Search Keywords:
1715035
IN STOCK: 573
Can Ship immediately
Manufacturer Stock:
757   can ship 10/25/24
Minimum Order:
10
Factory Lead-Time
5 Weeks can ship 11/15/24
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$1.90
$19.000
100
$1.42
$142.000
250
$1.40
$350.000
500
$1.33
$665.000
1,000
$1.31
$1,310.000
2,500
$1.29
$3,225.000
5,000
$1.27
$6,350.000
7,500 +
$1.25
$9,375.000
