DATA SHEET

1720046

Phoenix Contact

PCB terminal block - nominal current: 32 A - rated voltage (III/2): 630 V - nominal cross section: 4 mm² - pitch: 6.35 mm - number of positions: 3 - connection method: Screw connection with tension sleeve - mounting: Wave soldering - conductor/PCB connection direction: 35 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 5 mm. The article can be aligned to create different nos. of positions! .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1720046
Alias/AKA:
SMKDS 5/ 3-6 35
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack:
50
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
6.35 mm
Number of Circuits:
3
Maximum Voltage Rating:
630 V
Maximum Current Rating:
32 A
Wire Size:
10-24 AWG
Operating Temperature:
N/A
The PHOENIX CONTACT 1720046 is a versatile and reliable PCB terminal block that is perfect for a variety of electrical applications. With a nominal current of 32 A and a rated voltage of 630 V (III/2), this terminal block can handle high-power circuits with ease. The nominal cross section of 4 mm² allows for efficient power transmission, while the pitch of 6.35 mm ensures easy installation and alignment on the PCB.Featuring three positions, this terminal block offers flexibility in circuit design, and its screw connection with tension sleeve provides a secure and reliable connection. The mounting method of wave soldering ensures fast and efficient installation on the PCB.The conductor/PCB connection direction of 35° allows for optimal space utilization, while the green color adds a touch of visual appeal. The linear pinning pin layout enables straightforward circuit board design, and the solder pin with a length of 5 mm provides a reliable and robust connection.With the ability to align multiple articles to create different numbers of positions, the PHOENIX CONTACT 1720046 is a versatile and customizable solution for any electrical project.
Search Keywords:
1720046
IN STOCK: 1,030
Can Ship immediately
Minimum Order:
50
Multiple:
50
Factory Lead-Time
4 Weeks
