DATA SHEET

1720929

Phoenix Contact

PCB headers - nominal current: 41 A - rated voltage (III/2): 630 V - nominal cross section: 6 mm² - number of positions: 4 - pitch: 7.62 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 4.26 mm .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1720929
Alias/AKA:
PCV 5/ 4-GF-7 62
RoHS:
Yes
HTS:
8536694040
COO:
PL
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Wire to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
7.62 mm
Number of Contacts:
4
Maximum Voltage Rating:
630 V
Maximum Current Rating:
41 A
Termination Method:
Solder
Operating Temperature:
N/A
The PHOENIX CONTACT part 1720929 is a high-quality PCB header designed for reliable and efficient electrical connections. With a nominal current rating of 41 A and a rated voltage of 630 V, this header is suitable for a wide range of applications. The 6 mm² nominal cross section ensures stable and secure connections. Featuring 4 positions and a pitch of 7.62 mm, this header has a compact design that saves space on the PCB. The vibrant green color adds visual appeal and easy identification. The contact surface is coated with tin, providing excellent conductivity and corrosion resistance.Designed for ease of installation, this header is suitable for wave soldering. The linear pinning layout ensures straightforward connections and compatibility with various PCB designs. With a solder pin size of 4.26 mm, this header ensures reliable and secure soldering.Overall, the PHOENIX CONTACT part 1720929 is a dependable PCB header that combines high current and voltage capabilities with easy installation and durable construction.
Search Keywords:
1720929
IN STOCK: 221
Can Ship immediately
Manufacturer Stock:
86   can ship 11/15/24
Minimum Order:
5
Factory Lead-Time
4 Weeks can ship 12/3/24
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$7.25
$36.250
25
$6.68
$167.000
100
$5.85
$585.000
250
$5.40
$1,350.000
500
$5.14
$2,570.000
1,000
$4.85
$4,850.000
2,500
$4.78
$11,950.000
5,000 +
$4.70
$23,500.000
