DATA SHEET

1755532

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 4 - pitch: 5 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1755532
Alias/AKA:
MSTBVA 2 5/ 4-G
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5 mm
Number of Contacts:
4
Maximum Voltage Rating:
250@IEC,300@UL V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A
The PHOENIX CONTACT part 1755532 is a PCB header that is designed for various electrical applications. It has a nominal current rating of 12 A and a rated voltage of 320 V (III/2). With a nominal cross section of 2.5 mm², this header is capable of handling electrical connections efficiently.This PCB header features 4 positions, allowing for multiple connections to be made. The pitch of 5 mm ensures proper spacing between the positions, which aids in the organization of electrical connections. Additionally, the header is colored green, making it easily identifiable amongst other components.The contact surface of the header is coated with tin, which offers excellent conductivity and corrosion resistance. This ensures reliable and long-lasting electrical connections. The header is designed for wave soldering mounting, which provides a secure attachment to the PCB.The pin layout of the header is linear, making it straightforward to connect wires or other components in a straight line. The solder pin has a length of 3.9 mm, allowing for convenient soldering.Overall, the PHOENIX CONTACT part 1755532 is a reliable and versatile PCB header that fulfills various electrical connection requirements. Its high-quality construction and features make it a preferred choice for professionals in the field.
Search Keywords:
1755532
IN STOCK: 2,082
Can Ship immediately
Minimum Order:
25
Factory Lead-Time
6 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$1.442
$36.050
250
$1.202
$300.500
500
$1.183
$591.500
1,000
$1.072
$1,072.000
2,500
$1.056
$2,640.000
5,000
$1.030
$5,150.000
7,500
$1.014
$7,605.000
10,000 +
$0.999
$9,990.000
