1757116 by phoenix contact
DATA SHEET

1757116

Phoenix Contact

PCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 12 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1757116
Alias/AKA:
MSTB 2 5/12-ST-5 08
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
12
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A
The MSTB 2,5/12-ST-5,08 is a 12-position green pluggable PCB Terminal Block with tin-plated solder contacts, a polyamide insulator and the M3 screw connection. This 1757116 terminal block provides individual position coding by inserting coding profiles. It accepts 24 to 12AWG wire range. Green colour insulation Tin contact surface Plug-in direction parallel to the conductor axis Individual position coding by inserting coding profiles Polyamide (PA) insulating material UL94 V-0 flammability rating CSA, VDE, IECEE CB, CCA, EAC and cULus recognized Dimension of terminal block is 18.3mm x 15mm x 60.96mm (L x H x W) 7mm Stripping length Applications Industrial
Search Keywords:
1757116
IN STOCK: 1,494
Ships today, if you order in
Manufacturer Stock:
616   can ship 12/6/24
Minimum Order:
5
Factory Lead-Time
3 Weeks can ship 12/12/24
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$11.72
$58.600
25
$10.46
$261.500
50
$9.71
$485.500
100
$9.31
$931.000
250
$9.07
$2,267.500
500
$8.83
$4,415.000
1,000 +
$8.70
$8,700.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
