DATA SHEET

1777099

Phoenix Contact

PCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 4 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1777099
Alias/AKA:
MSTBV 2 5/ 4-GF-5 08
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Shrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
4
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A
The Phoenix Contact part 1777099 is a high-quality PCB header designed for secure and efficient electrical connections. With a nominal current rating of 12 A and a rated voltage of 320 V, this PCB header ensures reliable power transmission. It features 4 positions, a pitch of 5.08 mm, and a nominal cross-section of 2.5 mm², providing ample space for multiple wires. The green color adds visual distinction, making it easy to identify on your PCB.The contact surface is tin-plated, enhancing conductivity and preventing oxidation for long-lasting performance. The PCB header is specifically designed for wave soldering mounting, allowing for easy and efficient installation.With its linear pinning, it facilitates a straightforward pin layout for convenient connections. The solder pin has a length of 3.9 mm, providing secure solder joint formation. Overall, the Phoenix Contact part 1777099 is a reliable and versatile solution for your PCB connection needs, offering excellent electrical performance and ease of installation.
Search Keywords:
1777099
IN STOCK: 501
Ships today, if you order in
Manufacturer Stock:
4,686   can ship 11/18/24
Minimum Order:
5
Factory Lead-Time
6 Weeks can ship 12/17/24
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$3.71
$18.550
50
$2.81
$140.500
100
$2.74
$274.000
250
$2.66
$665.000
500
$2.61
$1,305.000
1,000
$2.58
$2,580.000
2,500
$2.54
$6,350.000
5,000 +
$2.50
$12,500.000
