Phoenix ContactPCB headers - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 5 - pitch: 5.08 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.9 mm .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1777109
Alias/AKA:
MSTBV 2 5/ 5-GF-5 08
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
5.08 mm
Number of Contacts:
5
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Termination Method:
Solder
Operating Temperature:
N/A
The PHOENIX CONTACT part 1777109 is a PCB header designed for reliable electrical connections. It features a nominal current of 12 A and a rated voltage (III/2) of 320 V, making it suitable for a variety of applications. The nominal cross-section is 2.5 mm², with 5 positions and a pitch of 5.08 mm. The headers are colored green and have a contact surface coated with tin for improved conductivity. They are designed for wave soldering mounting and have a linear pinning layout with solder pins measuring 3.9 mm in length.
Search Keywords:
1777109
IN STOCK:
300
Ships today, if you order in
Manufacturer Stock:
509
can ship
11/29/24
Minimum Order:
5
Factory Lead-Time
12 Weeks
can ship
2/7/25
Quantity
Unit Price
Ext. Price
5
$4.34
$21.700
50
$3.61
$180.500
100
$3.56
$356.000
250
$3.27
$817.500
500
$3.18
$1,590.000
1,000
$3.13
$3,130.000
2,500
$3.06
$7,650.000
5,000
+
$3.01
$15,050.000
Tools/3D Models
Product Guides
Datasheet
PCN - 01-Jan-2015 - INTRODUCTION OF 2D BARCODING
