1792799
Phoenix ContactPCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 6 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1792799
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack
50
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
6
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A
The PHOENIX CONTACT part 1792799 is a high-quality PCB connector designed for reliable and efficient electrical connections. It has a nominal current of 12 A and a rated voltage of 320 V (III/2). With a nominal cross-section of 2.5 mm², it is suitable for various applications. The connector features 6 positions and a pitch of 5.08 mm, providing flexibility in installation. The connection method is screw connection with a tension sleeve, ensuring secure and durable connections. The connector is color-coded in green, allowing for easy identification and organization. The contact surface is tin-plated, enhancing conductivity and corrosion resistance, resulting in optimal performance and longevity.
Search Keywords:
1792799
Possible Replacement options available. See Alternatives
IN STOCK:
833
Can Ship immediately
Manufacturer Stock:
7,564
can ship
11/18/24
Minimum Order:
5
Factory Lead-Time
6 Weeks
can ship
12/17/24
Quantity
Unit Price
Ext. Price
5
$5.406
$27.030
25
$5.035
$125.875
100
$4.956
$495.600
250
$4.907
$1,226.750
500
$4.858
$2,429.000
1,000
$4.809
$4,809.000
2,500
$4.761
$11,902.500
5,000
+
$4.713
$23,565.000
