DATA SHEET

1803374

Phoenix Contact

PCB headers - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 12 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.4 mm .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1803374
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Shrouded Header (4 Sides)
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
12
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A
The PHOENIX CONTACT PCB header part 1803374 is a high-quality electronic component designed for reliable and efficient circuit connections. With a nominal current rating of 8 A and a rated voltage of 160 V, it is capable of handling a wide range of power requirements. The header has 12 positions and a pitch of 3.81 mm, providing ample space for various connections. It is color-coded in green for easy identification and features a tin contact surface for enhanced conductivity. The header is designed for wave soldering mounting method and has a linear pinning layout for easy and secure installation. The solder pin has a length of 3.4 mm, ensuring a strong and durable connection. This PHOENIX CONTACT PCB header is a reliable choice for any electronic project.
Search Keywords:
1803374
IN STOCK: 401
Ships today, if you order in
Manufacturer Stock:
171   can ship 12/9/24
Minimum Order:
50
Multiple:
50
Factory Lead-Time
6 Weeks can ship 1/3/25
Enter Quantity
Quantity
Unit Price
Ext. Price
50
$4.22
$211.000
100
$3.98
$398.000
250
$3.82
$955.000
500
$3.72
$1,860.000
1,000
$3.62
$3,620.000
2,500
$3.57
$8,925.000
5,000
$3.51
$17,550.000
7,500 +
$3.46
$25,950.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
