DATA SHEET

1803617

Phoenix Contact

PCB connector - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 6 - pitch: 3.81 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1803617
Alias/AKA:
MC 1 5/ 6-ST-3 81
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
3.81 mm
Number of Circuits:
6
Maximum Voltage Rating:
160@IEC,300@UL V
Maximum Current Rating:
8 A
Wire Size:
16-28 AWG
Operating Temperature:
N/A
The 1803617 is a 6-position green pluggable PCB Terminal Block with tin-plated solder contacts, a polyamide insulator and the M2 screw connection. This MC 1,5/ 6-ST-3,81 terminal block has fully developed contact geometries and surfaces. It accepts 28 to 16AWG wire range. Generously dimensioned wiring space Plug-in direction parallel to the conductor axis Low design height of the MC 1,5 plug range 7mm Stripping length A1 Internal cylindrical gage UL94V-0 Flammability rating Applications Industrial
Search Keywords:
1803617
IN STOCK: 427
Ships today, if you order in
Manufacturer Stock:
5,923   can ship 12/2/24
Minimum Order:
5
Factory Lead-Time
3 Weeks can ship 12/6/24
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$7.14
$35.700
25
$6.33
$158.250
100
$5.61
$561.000
250
$5.31
$1,327.500
500
$5.23
$2,615.000
1,000
$5.10
$5,100.000
2,500
$5.02
$12,550.000
5,000 +
$4.95
$24,750.000
