1827156 by phoenix contact
DATA SHEET

1827156

Phoenix Contact

PCB connector - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 5 - pitch: 3.81 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1827156
Alias/AKA:
MCVR 1 5/ 5-ST-3 81
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:
250
Package Type:
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
3.81 mm
Number of Circuits:
5
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Wire Size:
16-28 AWG
Operating Temperature:
N/A
The PHOENIX CONTACT part 1827156 is a PCB connector with a compact design and reliable performance. It has a nominal current of 8 A, making it suitable for a wide range of applications. The rated voltage (III/2) is 160 V, ensuring safe and efficient operation. With a nominal cross section of 1.5 mm², this connector offers excellent electrical conductivity. It comes with 5 positions, providing ample space for wiring connections. The pitch of 3.81 mm allows for easy installation and maintenance.The connection method of this PCB connector is screw connection with tension sleeve, ensuring a secure and durable connection. Additionally, its green color adds visual distinction and ease of identification in complex circuit systems.To enhance its performance, the contact surface of this connector is coated with tin. This coating provides excellent conductivity, corrosion resistance, and protects against oxidation.Overall, the PHOENIX CONTACT part 1827156 is an excellent choice for PCB applications that require reliable, efficient, and secure connections.
Search Keywords:
1827156
IN STOCK: 960
Can Ship immediately
Manufacturer Stock:
9,616   can ship 10/25/24
Minimum Order:
5
Factory Lead-Time
4 Weeks can ship 11/8/24
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$5.47
$27.350
25
$4.54
$113.500
100
$4.39
$439.000
250
$4.28
$1,070.000
500
$4.20
$2,100.000
1,000
$4.13
$4,130.000
2,500
$4.07
$10,175.000
5,000 +
$4.01
$20,050.000
