DATA SHEET

1827871

Phoenix Contact

PCB headers - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 3 - pitch: 3.81 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.4 mm .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1827871
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.81 mm
Number of Contacts:
3
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
-40 to 100 °C
The PHOENIX CONTACT part 1827871 is a PCB header that is designed for high-performance electrical connections. It has a nominal current rating of 8 A and a rated voltage of 160 V. With a nominal cross section of 1.5 mm², this header is suitable for various applications.Featuring 3 positions and a pitch of 3.81 mm, this header offers a compact and efficient design. Its vibrant green color ensures easy identification and wiring organization. The contact surface is coated with tin, enhancing conductivity and corrosion resistance.The header is specifically designed for wave soldering mounting, ensuring secure and reliable solder connections. The pin layout follows a linear pinning arrangement, providing a straightforward and orderly connection process.With a solder pin length of 3.4 mm, this PCB header facilitates easy soldering and enhances the overall durability of the connection. It is a reliable and versatile component that meets the demanding requirements of various electrical applications.
Search Keywords:
1827871
IN STOCK: 2,522
Can Ship immediately
Manufacturer Stock:
752   can ship 10/28/24
Minimum Order:
10
Factory Lead-Time
6 Weeks can ship 11/22/24
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$3.18
$31.800
50
$2.27
$113.500
250
$2.20
$550.000
500
$2.16
$1,080.000
1,000
$2.13
$2,130.000
2,500
$2.10
$5,250.000
5,000
$2.07
$10,350.000
7,500 +
$2.04
$15,300.000
