1840379 by phoenix contact
DATA SHEET

1840379

Phoenix Contact

PCB connector - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 3 - pitch: 3.5 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1840379
Alias/AKA:
MC 1 5/ 3-ST-3 5
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
3.5 mm
Number of Circuits:
3
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Wire Size:
14-30 AWG
Operating Temperature:
N/A
The MC 1, 5/3-ST-3, 5 from Phoenix Contact is a 3 position pluggable terminal block with screw connection. This terminal block comes with 3.5mm pitch spacing and suitable for wire size ranging from 28AWG to 16AWG. Green colour insulation Tin contact surface Plug-in direction parallel to the conductor axis Individual position coding by removing the coding tab & connecting the coding profile to the header Polyamide (PA) insulating material CSA, VDE, IECEE CB, CCA, EAC and cULus recognized Dimension of terminal block is 11.1mm x 10.5mm (H x W) Applications Industrial
Search Keywords:
1840379
IN STOCK: 2,374
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
3 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$3.99
$19.950
50
$3.33
$166.500
100
$3.28
$328.000
250
$3.01
$752.500
500
$2.93
$1,465.000
1,000
$2.89
$2,890.000
2,500
$2.82
$7,050.000
5,000 +
$2.77
$13,850.000
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
