2320034
Phoenix ContactPrimary-switched QUINT DC/DC converter for DIN rail mounting with SFB (Selective Fuse Breaking) Technology - input: 24 V DC - output: 24 V DC/5 A .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2320034
Alias/AKA:
QUINT-PS/24DC/24DC/ 5
RoHS:
Yes
HTS:
8504407007
COO:
IN
ECCN:
EAR99
Supplier Standard Pack
1
Input Voltage:
14 to 32 V
Number of Outputs:
1
Output Voltage:
24 V
Output Current:
5 A
Output Power:
120 W
Mounting:
DIN Rail
Type:
Step Down
Dimension:
125 x 32 x 130 mm
Output Type:
Fixed
Family:
2320034
2320034 is a QUINT mini DC/DC converter which alter the voltage level, regenerate the voltage at the end of long cables or enable the creation of independent supply systems by means of electrical isolation. It has a nominal input voltage range of 18 to 32 VDC, nominal output voltage of 24VDC, nominal output current of 5A, selective fuse breaking of 30 A (12 ms) and efficiency of 92% or higher. The product can be mounted in horizontal DIN rail, and can also be connected in series or parallel. Connection at input and output is through M3 pluggable screw connection. Product's dimensions are 32mm x 130mm x 125mm (wxhxd).
Search Keywords:
2320034
IN STOCK:
0
On Order:
15
can ship 12/11/24
Factory Lead-Time
15 Weeks
Quantity
Unit Price
Ext. Price
1
$333.73
$333.730
3
$320.02
$960.060
5
$311.48
$1,557.400
10
$306.81
$3,068.100
15
+
$302.21
$4,533.150
