DATA SHEET

2320102

Phoenix Contact

Primary-switched QUINT DC/DC converter for DIN rail mounting with SFB (Selective Fuse Breaking) Technology - input: 24 V DC - output: 24 V DC/20 A .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2320102
Alias/AKA:
QUINT-PS/24DC/24DC/20
RoHS:
Yes
HTS:
8504407012
COO:
IN
ECCN:
EAR99
Supplier Standard Pack:
1
Input Voltage:
14 to 32 V
Number of Outputs:
1
Output Voltage:
24 V
Output Current:
20 A
Output Power:
480 W
Mounting:
DIN Rail
Type:
Step Down
Dimension:
125 x 82 x 130 mm
Output Type:
Fixed
Family:
2320102
2320102 is a QUINT mini DC/DC converter which alter the voltage level, regenerate the voltage at the end of long cables or enable the creation of independent supply systems by means of electrical isolation. It has a nominal input voltage range of 18 to 32 VDC, nominal output voltage of 24VDC, nominal output current of 20A, selective fuse breaking of 120A (12 ms) and efficiency of 93% or higher. The product can be mounted in horizontal DIN rail, and can also be connected in series or parallel. Connection at input and output is through M3 pluggable screw connection. Product's dimensions are 82mm x 130mm x 125mm (wxhxd).
Search Keywords:
2320102
IN STOCK: 27
Ships today, if you order in
Manufacturer Stock:
161   can ship 10/28/24
Factory Lead-Time
11 Weeks can ship 12/27/24
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$577.62
$577.620
3
$568.96
$1,706.880
5
$560.42
$2,802.100
10 +
$552.01
$5,520.100
DOWNLOADS
PDF Datasheet
Request Free CAD Models
