Phoenix ContactDouble-level terminal block - connection method: Screw connection - cross section: 0.2 mm² - 4 mm² - AWG: 24 - 12 - width: 6.2 mm - color: gray - mounting type: NS 35/7,5 - NS 35/15 - NS 32 .. see full description
- RoHS Compliant
- Set Notification
-
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2774017
Alias/AKA:
UKK 5
RoHS:
Yes
HTS:
8536904000
COO:
IN
ECCN:
EAR99
Supplier Standard Pack:
50
Type:
Double-Level Terminal Block
Mounting:
G DIN Rail,T DIN Rail
Gender:
F
Termination Method:
Screw
Pitch:
N/A
Number of Circuits:
1
Maximum Voltage Rating:
500 V
Maximum Current Rating:
32 A
Wire Size:
12-24 AWG
Operating Temperature:
N/A
The 2774017 is a Double-level Terminal Block Connector
Type: Wire to Wire
Number of Positions: 4 Position
Current Rating: 32 A
Voltage Rating: 500 V
Wire Gauge Range: 24 AWG to 12 AWG
Connection Method: Screw
Color: Gray
Flammability Rating: UL 94 V-0
Length: 56 mm
Width: 6.2 mm
Height: 67 mm
Search Keywords:
2774017
IN STOCK:
2,075
Can Ship immediately
Manufacturer Stock:
4,765
can ship
10/28/24
Minimum Order:
5
Factory Lead-Time
5 Weeks
can ship
11/18/24
Quantity
Unit Price
Ext. Price
5
$7.51
$37.550
25
$6.45
$161.250
50
$6.05
$302.500
100
$5.43
$543.000
250
$5.35
$1,337.500
500
$5.27
$2,635.000
1,000
$5.19
$5,190.000
2,500
+
$5.12
$12,800.000
Datasheet
