3044584
Phoenix ContactFeed-through terminal block - nom. voltage: 500 V - nominal current: 32 A - connection method: Screw connection - number of connections: 4 - cross section: 0.14 mm² - 6 mm² - AWG: 26 - 10 - width: 6.2 mm - height: 46.9 mm - color: blue - mounting type: NS 35/7,5 - NS 35/15 .. see full description
- RoHS Compliant
- Set Notification
-
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3044584
Alias/AKA:
UT 4-QUATTRO BU
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:
50
Type:
Feed-Through Terminal Block
Mounting:
T DIN Rail
Gender:
F
Termination Method:
Screw
Pitch:
N/A
Maximum Voltage Rating:
500 V
Maximum Current Rating:
32 A
Wire Size:
10-26 AWG
Operating Temperature:
N/A
Feed-through terminal block - nom. voltage: 500 V - nominal current: 32 A - connection method: Screw connection - number of connections: 4 - cross section: 0.14 mm² - 6 mm² - AWG: 26 - 10 - width: 6.2 mm - height: 46.9 mm - color: blue - mounting type: NS 35/7,5 - NS 35/15
Search Keywords:
3044584
IN STOCK:
450
Ships today, if you order in
Manufacturer Stock:
176
can ship
10/25/24
Minimum Order:
50
Multiple:
50
Factory Lead-Time
5 Weeks
can ship
11/15/24
Quantity
Unit Price
Ext. Price
50
$1.98
$99.000
100
$1.95
$195.000
250
$1.92
$480.000
500
$1.89
$945.000
1,000
$1.87
$1,870.000
2,500
$1.84
$4,600.000
5,000
$1.81
$9,050.000
7,500
+
$1.78
$13,350.000
