3046223
Phoenix ContactGround modular terminal block - connection method: Screw connection - cross section: 0.14 mm² - 6 mm² - AWG: 26 - 10 - length: 57.8 mm - width: 6.2 mm - color: green-yellow - mounting: NS 35/7,5 - NS 35/15 .. see full description
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3046223
Alias/AKA:
UT 4-MTD-PE
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack
50
Type:
Ground Modular Terminal Block
Mounting:
T DIN Rail
Gender:
F
Termination Method:
Screw
Pitch:
N/A
Number of Circuits:
1
Maximum Voltage Rating:
N/A
Maximum Current Rating:
N/A
Wire Size:
10-26 AWG
Operating Temperature:
N/A
The PHOENIX CONTACT part 3046223 is a ground modular terminal block with a screw connection method. It is designed for a wide range of applications and features a cross section range of 0.14 mm² to 6 mm², making it suitable for various wire thicknesses. With an AWG range of 26 to 10, it can accommodate different wire gauges. The terminal block has a compact design with dimensions of 57.8 mm in length and 6.2 mm in width, allowing for easy installation in limited space. Its green-yellow color ensures easy identification for grounding purposes. The mounting options include NS 35/7,5 and NS 35/15, providing versatility and compatibility with common mounting rails. Overall, the PHOENIX CONTACT part 3046223 is a reliable and efficient choice for secure grounding connections in various industrial and commercial applications.
Search Keywords:
3046223
IN STOCK:
536
Ships today, if you order in
Manufacturer Stock:
1,018
can ship
11/29/24
Minimum Order:
50
Multiple:
50
Factory Lead-Time
5 Weeks
can ship
12/20/24
Quantity
Unit Price
Ext. Price
50
$4.25
$212.500
100
$4.02
$402.000
250
$3.87
$967.500
500
$3.78
$1,890.000
1,000
$3.68
$3,680.000
2,500
$3.63
$9,075.000
5,000
$3.57
$17,850.000
7,500
+
$3.52
$26,400.000
