TSM-103-01-S-SV-P-TR by Samtec
DATA SHEET

TSM-103-01-S-SV-P-TR

Samtec

Board-To-Board Connector - 2.54 mm - 3 Contacts - Header - Surface Mount - 1 Rows. .. see full description

  • RoHS Compliant
  • REEL Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
TSM-103-01-S-SV-P-TR
RoHS:
Yes
HTS:
8536694040
COO:
CR
ECCN:
EAR99
Package Type:
REEL
Type:
Unshrouded Header3594
Body Orientation:
Straight3574
Gender:
HDR3578
Mounting:
Surface Mount3586
Pitch:
2.54 mm
Number of Contacts:
3
Maximum Voltage Rating:
4753584VAC
Maximum Current Rating:
5.4/Contact A
Termination Method:
Solder3593
Operating Temperature:
-55 to 125 °C
The TSM series from Samtec are surface mount terminal strip headers. These are unshrouded headers with 0.25" (0.635mm) square post and mates with Samtec SSW, SSQ, SSM, BSW, ESW, ESQ, BCS, SLW, CES, HLE, IDSS, IDSD, SMSD and SMSS series of connectors. There is choice of standard post heights which provides solution to mate with any Samtec sockets. This contactor has high operating temperature range from -55°C to 125°C for 30µ" gold plated contacts. Tipical aplication is industrial.
Search Keywords:
TSM10301SSVPTR
IN STOCK: 20,766
Ships today, if you order in
Manufacturer Stock:
22,497   can ship 7/26/24
Factory Lead-Time
3 Weeks can ship 8/1/24
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$1.0158
$1.016
325
$0.8333
$270.823
650
$0.7255
$471.575
1,300
$0.6439
$837.070
2,600
$0.6195
$1,610.700
5,200
$0.5561
$2,891.720
10,075
$0.4585
$4,619.388
25,025 +
$0.3756
$9,399.390
