TSW-104-07-T-S by samtec
DATA SHEET

TSW-104-07-T-S

Samtec

Board-To-Board Connector - 2.54 mm - 4 Contacts - Header - Through Hole - 1 Row. .. see full description

  • RoHS Compliant
  • BULK Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Samtec
Part No:
TSW-104-07-T-S
RoHS:
Yes
HTS:
8536694040
COO:
US
ECCN:
EAR99
Supplier Standard Pack:
1
Package Type:
BULK
Type:
Unshrouded Header
Body Orientation:
Straight
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
4
Maximum Voltage Rating:
550 VAC
Maximum Current Rating:
6.3/Contact A
Termination Method:
Solder
Operating Temperature:
-55 to 105 °C
The TSW series from Samtec are standard terminal strip headers. These are unshrouded through hole headers with 0.025" (0.635mm) square post and mates with Samtec SSW, SSQ, SSM, ESW, ESQ, BCS, BSW, CES, SLW, IDSD, IDSS, SMSD and SMSS series of connectors. These connectors features single, double and triple row options with straight or right angle pins in a variety of post heights and body positions. It is an Extended Life Product™, passing 10 year Mixed Flowing Gas (MFG) with 30µ" gold and achieving high mating cycles (250 to 2500). These connectors has gold flash on post, matte tin on tail/10µ" (0.25µm) gold on post, matte tin on tail/10µ" (0.25µm) gold on post/gold flash on balance/matte tin plating options. TSW series connectors are available with industry's largest variety of standard pin counts, terminal lengths and are used where signal integrity and reliability is of major concern.
Search Keywords:
TSW10407TS
IN STOCK: 5,914
Can Ship immediately
Manufacturer Stock:
4,312   can ship 10/28/24
Minimum Order:
250
Factory Lead-Time
3 Weeks can ship 11/4/24
Enter Quantity
Quantity
Unit Price
Ext. Price
250
$0.1271
$31.775
2,500
$0.0896
$224.000
5,000
$0.0788
$394.000
7,500
$0.0735
$551.250
25,000
$0.0585
$1,462.500
50,000
$0.0576
$2,880.000
100,000
$0.0568
$5,680.000
150,000 +
$0.0559
$8,385.000
