199X-13 by schneider electric-legacy relays
DATA SHEET

199X-13

Schneider Electric-Legacy Relays

Electromechanical Relay DPDT 40A 24VDC 290Ohm .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
199X-13
Alias/AKA:
W199X-13
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
40 A
Mounting:
N/A
Termination Style:
Screw Terminal
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 55 °C
The Magnecraft / Schneider Electric Part 199X-13 is a highly reliable and durable electromechanical relay that is perfect for a wide range of applications. This double-pole, double-throw (DPDT) relay has a high current rating of 40A and operates at a low voltage of 24VDC. With a low coil resistance of 290 ohms, this relay effectively switches between multiple power sources, making it ideal for use in various industrial and automotive settings. The Magnecraft / Schneider Electric Part 199X-13 is built to withstand demanding environments and provides excellent performance and longevity.
Search Keywords:
199X13
IN STOCK: 0
On Order:
500   can ship 12/2/24
500   can ship 12/23/24
253   can ship 2/17/25
Factory Lead-Time
16 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$51.70
$51.700
5
$50.93
$254.650
10
$46.46
$464.600
30
$45.62
$1,368.600
50
$43.08
$2,154.000
100
$40.56
$4,056.000
250 +
$39.95
$9,987.500
Suppliers Standard Package
Tools/3D Models
Request Free CAD Models
