92S11D22D-12 by Schneider Electric-Legacy Relays
DATA SHEET

92S11D22D-12

Schneider Electric-Legacy Relays

Electromechanical Relay 12VDC 86Ohm 20ADC/30AAC DPDT (68.5x34.5x37.81)mm Flange/DIN Rail Power Relay .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
92S11D22D-12
Alias/AKA:
W92S11D22D-12
RoHS:
Yes
HTS:
8536410050
ECCN:
EAR99
Coil Current:
139.53 mA
AC Coil Voltage:
N/A
The Magnecraft / Schneider Electric 92S11D22D-12 is an electromechanical relay designed for high power applications. With a coil voltage of 12VDC and a coil resistance of 86 Ohms, this relay provides reliable switching and control for various electrical systems. Featuring a double-pole double-throw (DPDT) configuration, the 92S11D22D-12 allows for versatile control of two separate circuits. It can handle a maximum current of 20ADC and 30AAC, making it suitable for a wide range of industrial and commercial applications.Measuring at 68.5x34.5x37.81mm, this relay can be easily mounted using the included flange/DIN rail power relay. It is designed to provide dependable performance and long-lasting durability in demanding environments.Whether used in automation systems, HVAC equipment, or power distribution units, the Magnecraft / Schneider Electric 92S11D22D-12 is a reliable choice for controlling high-power circuits. With its compact size and versatile design, it offers seamless integration into various electrical systems.
Search Keywords:
92S11D22D12
IN STOCK: 394
Can Ship immediately
Manufacturer Stock:
1,950   can ship 7/22/24
On Order:
10   can ship 9/6/24
Factory Lead-Time
9 Weeks can ship 9/9/24
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$22.77
$22.770
10
$15.61
$156.100
30
$15.44
$463.200
50
$15.36
$768.000
100
$15.29
$1,529.000
250
$15.21
$3,802.500
500 +
$15.13
$7,565.000
Older Equivalent
W92S11D22D-12
W92S11D22D-12
