DATA SHEET

W107DIP-8

Schneider Electric-Legacy Relays

Reed Relay, Dry - SPST-NO - 14 DIP (8 Leads) - w/Diode - 0.5A/10W - 100Vdc/ACPk - 24Vdc .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
Discontinued
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
W107DIP-8
Alias/AKA:
107DIP-8
RoHS:
Yes
HTS:
8536410020
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Package Type:
Type:
Dry
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Maximum AC Switching Voltage:
120 V
Maximum DC Switching Voltage:
100 V
Maximum Carry Current:
0.5 A
Maximum Switching Current:
0.5 A
Maximum Switching Power:
10 VA
Package Type:
DIP
Terminal Type:
PC Pin
Mounting:
Through Hole
Life Cycle:
Discontinued
The Magnecraft / Schneider Electric part W107DIP-8 is a high-quality reed relay designed for various electronic applications. With a 24VDC coil voltage and 2KOhm coil resistance, this relay is capable of switching up to 0.5A of current. It features a single-pole, single-throw normally open configuration, making it suitable for controlling circuits in a variety of devices.The compact size of this reed relay, measuring 19x7.62x7.49mm, allows for easy integration into tight spaces. Designed for through-hole mounting, it offers a secure and stable connection when installed onto a PCB. The dry contacts of the relay ensure reliable and efficient switching operations.Ideal for use in industrial control systems, telecommunications equipment, and other electronic devices, the Magnecraft / Schneider Electric W107DIP-8 reed relay provides a dependable solution for switching and control applications.
Search Keywords:
W107DIP8
  This product is discontinued, but still in stock
IN STOCK: 6,064
Ships today, if you order in
Minimum Order:
5
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$9.05
$45.250
25
$8.18
$204.500
50
$7.80
$390.000
100
$7.56
$756.000
250
$7.14
$1,785.000
500
$6.94
$3,470.000
1,000 +
$6.83
$6,830.000
