W171DIP-23 by Schneider Electric-Legacy Relays
DATA SHEET

W171DIP-23

Schneider Electric-Legacy Relays

Reed Relays 12VDC 1KOhm 0.5A DPST-NO (19x7.62x7.49)mm THT Dry .. see full description

  • RoHS Compliant
  • Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
  • Discontinued
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
W171DIP-23
RoHS:
Yes
HTS:
8536410020
COO:
CN
ECCN:
EAR99
Package Type:
Type:
Dry
DC Coil Voltage:
12 V
Contact Arrangement:
DPST-NO
Maximum AC Switching Voltage:
60 V
Maximum DC Switching Voltage:
100 V
Maximum Carry Current:
0.5 A
Maximum Switching Current:
0.5 A
Maximum Switching Power:
10 VA
Package Type:
DIP
Terminal Type:
PC Pin
Mounting:
Through Hole
Life Cycle:
Discontinued
The Magnecraft / Schneider Electric W171DIP-23 is a compact and versatile reed relay designed for a variety of applications. With a voltage rating of 12VDC and a contact resistance of 1KOhm, this relay offers reliable and efficient control for your electrical circuits. The relay features a double-pole single throw normally open configuration, making it suitable for both high-power and low-power applications. Measuring at 19x7.62x7.49mm, the W171DIP-23 can easily be integrated into your existing electronic systems. This through-hole mounted relay is designed for dry environments, ensuring reliable operation in various conditions. Whether you need to switch power, control signals, or other types of electrical currents, this Magnecraft / Schneider Electric reed relay is built to meet your needs.
Search Keywords:
W171DIP23
  This product is discontinued, but still in stock
IN STOCK: 629
Can Ship immediately
Minimum Order:
10
Multiple:
10
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$9.14
$91.400
30
$7.38
$221.400
50
$7.27
$363.500
100
$7.04
$704.000
250
$6.44
$1,610.000
500
$6.35
$3,175.000
1,000 +
$6.25
$6,250.000
Older Equivalent
W117DIP-11
