LR1200480D25 by sensata / crydom
DATA SHEET

LR1200480D25

Sensata / Crydom

DIP Solid State Relay - Control Voltage 4-32 VDC - Operating Voltage 48-530 VAC - Load Current 25 A - 1200 Vpk - PCB Mount - 1 Form A .. see full description

RoHS Compliant
EACH Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
LR1200480D25
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
530 V
Maximum Output Current:
25 A
Output Device:
SCR
Input Type:
DC
Input Voltage:
32 V
Mounting:
Through Hole
Circuit Arrangement:
1 Form A
Dimension:
35 x 28.4 x 6.3 mm
The LR1200480D25 is a SSR LR Series with SCR output for heavy industrial loads. Input control voltage range is 4-32 VDC. Typical input current is 9 mADC. Output operating voltage is 48-530 VAC and max load current is 25 A. Blocking voltage is 1200 Vpk. Switching type: zero voltage turn-on. I/O dielectric strenght is 2500 Vrms.
Search Keywords:
LR1200480D25
IN STOCK: 113
Can Ship immediately
Factory Lead-Time
8 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
1
$52.16
$52.160
5
$46.28
$231.400
20
$43.69
$873.800
40
$43.26
$1,730.400
60
$42.82
$2,569.200
100
$42.00
$4,200.000
260 +
$41.58
$10,810.800
