896H-1CH-D1-12VDC by song chuan
DATA SHEET

896H-1CH-D1-12VDC

Song Chuan

Power Relay 12VDC 50(NO)/30(NC)A SPDT(31.3x25.8)mm Socket Automotive .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Song Chuan
Part No:
896H-1CH-D1-12VDC
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5200
Contact Form:
1 Form C
Relay Construction:
Non-Latching
Coil Current:
133 mA
Coil Resistance:
90 Ohm
Contact Material:
Silver Tin Oxide
Operate Time:
20 ms
Seal:
Unsealed
Mounting:
Socket
Termination Style:
Quick Connect
Operating Temperature:
-40 to 125 °C
The SONG CHUAN 896H-1CH-D1-12VDC is a high-quality power relay designed for automotive applications. It is a 12VDC relay with a rugged construction and features a SPDT (single-pole double-throw) configuration. The relay has a 50A normally open (NO) contact rating and a 30A normally closed (NC) contact rating, making it suitable for various electrical systems in vehicles. With its compact size of 31.3x25.8mm, the relay can easily fit into standard automotive relay sockets. It is a reliable and durable choice for any automotive power control applications.
Search Keywords:
896H1CHD112VDC
IN STOCK: 4,980
Ships today, if you order in
Minimum Order:
10
Factory Lead-Time
30 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$4.00
$40.000
100
$3.16
$316.000
250
$2.92
$730.000
500
$2.67
$1,335.000
1,000
$2.63
$2,630.000
2,500
$2.59
$6,475.000
5,200
$2.55
$13,260.000
10,400 +
$2.52
$26,208.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
