15BL8MX by switchcraft
DATA SHEET

15BL8MX

Switchcraft

DIN Audio / Video Connector - 8 Contacts - Plug - Cable Mount - Solder - Tin Plated Contacts - Metal Body. .. see full description

RoHS Compliant
Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
Switchcraft
Part No:
15BL8MX
RoHS:
Yes
HTS:
8536694030
COO:
TW
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
75
Type:
DIN Connector
Gender:
Pin
Body Orientation:
Straight
Mounting:
Cable Mount
Housing Material:
N/A
Number of Contacts:
8
Contact Plating:
N/A
Termination Method:
Solder
Operating Temperature:
N/A
The 15BL8MX is a 8-contact Cord Plug with shielded barrel. Two piece metal barrel surrounds pin insert to form an electrical shield. The entire insert assembly is held together by snapping the insulated plastic shell over the assembly. The barrels special metal tab locks the shell in place.
Search Keywords:
15BL8MX
IN STOCK: 1,592
Ships today, if you order in
Minimum Order:
5
Factory Lead-Time
8 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$10.91
$54.550
25
$9.18
$229.500
75
$8.20
$615.000
150
$8.07
$1,210.500
300
$7.95
$2,385.000
525
$7.83
$4,110.750
1,050 +
$7.71
$8,095.500
