Supplier:
TE Connectivity / ABB Entrelec
Part No:
1SNK705510R0000
RoHS:
Yes
HTS:
8536904000
COO:
FR
ECCN:
EAR99
Supplier Standard Pack
25
Package Type:
Box
Product Height:
99.6 mm
UL Flammability Rating:
UL 94V-0
Gauge Type:
A2 / 2.3 mm Dia.
Impulse Withstanding Voltage Rating (IEC):
8000 V
Operating Voltage Rating (UL & CSA) (Max) - Main Circuit:
300 V
Short-Time Withstanding Current Rating @ 1s:
300 A
Voltage Rating (CSA):
300 V
Modular Terminal Block Product Type:
PI-Spring Terminal Block
Number of Levels:
3
Block Function:
Feed-Through
Current Rating (IEC):
22 A
Power Loss:
2.4 W
Current Rating (UL):
20 A
Current Rating (CSA):
20 A
IP Rating:
IP20
Connector Mounting Type:
DIN Rail
Voltage Rating (IEC):
500 V
Product Depth:
73.84 mm
Number of Circuits:
3
Number of Positions:
6
Primary Product Color:
Gray
Product Length:
73.84 mm
Housing Material:
Polyamide
Tool Size:
.138 in, 3.5 mm
Product Spacing:
.205 in, 5.2 mm
Main Circuit Capacity - Twin Ferrule per Spring Clamp:
26 – 20 AWG, .22 – .5 mm²
DIN Rail Mounting Type:
TH35-15 , TH35-7.5
Installation Temperature Range:
-5 – 40 °C, 23 – 104 °F
Product Weight:
17.33 g, .682 oz
Wire Stripping Length:
.433 in, 11 mm
Main Circuit Capacity - 1 Insulated Ferrule per Spring Clamp:
26 – 14 AWG, .22 – 2.5 mm²
Operating Temperature Range:
-55 – 110 °C, -67 – 230 °F
Dielectric Withstanding Voltage (Max):
2000 V
