DATA SHEET

7022PF

TE Connectivity / Agastat Brand

Industrial Electropneumatic Timing Relay - 2FormC - DPDT - 1 to 10 min Off Delay - 125VDC .. see full description

RoHS Non-Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Agastat Brand
Part No:
7022PF
Alias/AKA:
2-1423164-7
RoHS:
No
HTS:
8536410050
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Panel Mount
Type:
Time Delay Relay
Contact Arrangement:
DPDT
DC Coil Voltage:
125 V
AC Coil Voltage:
N/A
Contact Form:
2 Form C
Maximum Current Rating:
10 A
Termination Style:
Screw Terminal
Time Range:
1 to 10 min
The TE Connectivity / Agastat Brand part 7022PF is a reliable and high-quality industrial electropneumatic timing relay. This timing relay features a 2FormC double pole double throw (DPDT) configuration and a 1 to 10-minute off delay. With a voltage rating of 125VDC, this timing relay is perfect for various industrial applications where precise timing control is required. It is designed to ensure accurate and consistent timing intervals, enhancing the efficiency and effectiveness of pneumatic systems. The 7022PF timing relay is an excellent choice for industries that rely on precise timing sequences for optimal operational performance.
Product Highlights:
  • 7000 Electropneumatic Timing Series
  • Time Delay Relay
  • Input Voltage = 125 VDC
  • Contact Arrangement = 2 Form C, DPDT, 2 C/O
  • Contact Rating = 10A @ 240 VAC
Search Keywords:
7022PF
IN STOCK: 9
Ships today, if you order in
MOQ for out of Stock Qty:
2
Factory Lead-Time
45 Weeks
Limited Availability. There is currently no price for this item
Call us to request pricing.
