ADE0204 by te connectivity / alcoswitch brand
DATA SHEET

ADE0204

TE Connectivity / Alcoswitch Brand

Switch DIP OFF ON SPST 2 Raised Slide 0.1A 24VDC PC Pins 2.54mm Thru-Hole Tube .. see full description

RoHS Compliant
Tube Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADE0204
Alias/AKA:
1825057-1
RoHS:
Yes
HTS:
8536509032
COO:
CH
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
60
Package Type:
Tube
Body Orientation:
Straight
Actuator Style:
Raised Slide
Actuator Length:
1 mm
Number of Positions:
2
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.1@24VDC A
Contact Plating:
Gold Flash/Nickel
Terminal Pitch:
2.54 mm
The ADE0204 is a versatile DIP switch from TE Connectivity's Alcoswitch Brand that is designed for various applications. This SPST (Single Pole Single Throw) switch features a durable construction with 2 raised slides, ensuring easy and reliable operation. With a maximum current rating of 0.1A and a voltage rating of 24VDC, it can handle a wide range of electrical loads. The switch is designed for easy installation with PC pins and a 2.54mm pitch, making it compatible with standard PCB mounting. It is supplied in a convenient tube packaging, ensuring secure storage and transportation.
Product Highlights:
  • DIP Switch
  • PCB Mount Style = Through Hole
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Extended, Slide
  • Not Sealed
Search Keywords:
ADE0204
IN STOCK: 17,385
Ships today, if you order in
Minimum Order:
60
Multiple:
60
Factory Lead-Time
17 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
60
$0.6539
$39.234
300
$0.4093
$122.790
540
$0.4014
$216.756
1,020
$0.3853
$393.006
2,520
$0.3795
$956.340
5,040
$0.3756
$1,893.024
7,500
$0.3717
$2,787.750
10,020 +
$0.3680
$3,687.360
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
Product Guides
PDF Datasheet
