DATA SHEET

ADP0404

TE Connectivity / Alcoswitch Brand

Switch DIP OFF ON SPST 4 Piano 0.1A 24VDC 0.4VA PC Pins 2.54mm Thru-Hole .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
ADP0404
Alias/AKA:
1571999-6
RoHS:
Yes
HTS:
8536509032
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
35
Package Type:
Pack
Body Orientation:
Straight
Actuator Style:
Piano
Actuator Length:
2.11 mm
Number of Positions:
4
Pole Throw Configuration:
SPST
Mounting:
Through Hole
Terminal Type:
PC Pins
Contact Rating @ Voltage:
0.4@20VDC A
Contact Plating:
Gold/Nickel
Terminal Pitch:
2.54 mm
The TE Connectivity / Alcoswitch Brand part ADP0404 is a high-quality DIP switch designed for various electronic applications. With a compact size and sturdy construction, this switch features a SPST configuration and is capable of handling a current of up to 0.1A and a voltage of 24VDC, making it suitable for a wide range of circuits. The switch also has a low power consumption of 0.4VA, ensuring efficient operation. The PC pins with a 2.54mm pitch allow for easy and secure through-hole mounting, providing a reliable connection. Whether used in consumer electronics, industrial equipment, or other electronic devices, the ADP0404 switch guarantees reliable performance and precise control.
Product Highlights:
  • DIP Switch
  • PCB Mount Style = Through Hole
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Actuator Style = Piano (Side Actuated)
  • Not Sealed
Search Keywords:
ADP0404
  Possible Replacement options available.  See Alternatives
IN STOCK: 16,499
Ships today, if you order in
Minimum Order:
35
Multiple:
35
Factory Lead-Time
22 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
35
$1.176
$41.160
280
$0.763
$213.640
525
$0.735
$385.875
1,015
$0.702
$712.530
2,520
$0.692
$1,743.840
5,005
$0.681
$3,408.405
7,525
$0.671
$5,049.275
10,010 +
$0.661
$6,616.610
Please Note: Item may be subject to tariff fee if shipping within the United States
