102387-8 by TE Connectivity / Amp Brand
DATA SHEET

102387-8

TE Connectivity / Amp Brand

34 Position Rectangular Housing Connector Receptacle Black 0.100" (2.54mm) .. see full description

  • RoHS Compliant
  • Pack Packaging
  • Accessories
  • Set Notification
  • Request Programming Quote
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
102387-8
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
34
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
3/Contact A
Operating Temperature:
-65 to 105 °C
The 102387-8 is a 34-position 2-row Receptacle Housing with beryllium copper contacts and crimp termination and it is used with AMPMODU socket. The Mod IV series connector provides dual cantilever contact beam with built-in anti-overstress for reliable mating. UL94V-0 Flammability rating 2.54mm Pitch spacing 250V Voltage rating 5000MΩ Insulation resistance -65 to +105°C Temperature range Rugged Applications Automotive, Portable Devices, Consumer Electronics, Gaming, Medical, Instrumentation, Test & Measurement, Industrial Automation, Telecommunications
Product Highlights:
  • Receptacle Housing
  • Wire Termination Type = Crimp
  • Number of Positions = 34
  • Housing Type = Receptacle
  • Number of Rows = Dual
Search Keywords:
1023878
IN STOCK: 1,859
Can Ship immediately
Minimum Order:
5
Factory Lead-Time
26 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
5
$5.189
$25.945
25
$4.209
$105.225
100
$4.079
$407.900
250
$4.039
$1,009.750
500
$4.019
$2,009.500
1,000
$3.999
$3,999.000
2,500
$3.979
$9,947.500
5,000 +
$3.959
$19,795.000
