1-174357-2 by te connectivity / amp brand
DATA SHEET

1-174357-2

TE Connectivity / AMP Brand

070 EJ-2(+) PLUG ASSY 3P SIR .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-174357-2
RoHS:
Yes
HTS:
8538906000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Bag
Connector System:
Wire-to-Wire
UL Flammability Rating:
UL 94V-2
Nominal Voltage Architecture:
12 V
Connector Position Assurance Capable:
No
Serviceable:
Yes
Connector & Housing Type:
Housing for female terminals
Sealable:
Yes
Operating Voltage:
12 VDC
Primary Product Color:
Black
Number of Positions:
3
Packaging Quantity:
100
Number of Rows:
1
Primary Locking Feature:
Integrated in Housing
Circuit Application:
Signal
Packaging Method:
Bag
Terminal Position Assurance:
Yes
Cable Exit Angle:
180°
Operating Temperature Range:
-30 – 105 °C, -22 – 221 °F
Mating Tab Width:
.071 in, 1.8 mm
Operating Temperature (Max):
100 °C, 105 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 158 °F, 167 °F, 176 °F
Centerline (Pitch):
.189 in, 4.8 mm
Product Length:
1.087 in, 27.6 mm
Product Width:
1 in, 25.4 mm
Housing Material:
PBT
Connector Height:
.898 in, 22.8 mm
Contact Size:
1.8mm
Contact Type:
Receptacle
Strain Relief:
Without
Mating Alignment Type:
Polarization Slot
Mating Alignment:
With
Connector Shape:
Rectangular
Connector Mounting Type:
Cable Mount (Free-Hanging)
The TE Connectivity / AMP Brand part 1-174357-2 is a 070 EJ-2(+) Plug Assembly. It is a 3P (3-pin) SIR (Stowage-In-Readiness) plug assembly that provides a reliable and secure connection for various applications. This plug assembly is designed for easy installation and offers excellent performance and durability. It is a versatile solution for connecting and disconnecting electrical components and can be used in a wide range of industries.
Search Keywords:
11743572
IN STOCK: 3,000
Ships today, if you order in
Minimum Order:
100
Multiple:
100
Factory Lead-Time
24 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
100
$0.953
$95.300
300
$0.939
$281.700
500
$0.929
$464.500
1,000
$0.920
$920.000
2,500
$0.911
$2,277.500
5,000
$0.895
$4,475.000
7,500
$0.886
$6,645.000
10,000 +
$0.877
$8,770.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
