Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Amp Brand
Part No:
130005
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Package Type:
Box
Type:
PIDG Ring Tongue Terminal
Gender:
N/A
Tab Size:
N/A
Stud Size:
4.82 mm
Wire Size:
16-22 AWG
Color:
Red
Operating Temperature:
N/A
TE Connectivity / AMP Brand part 130005 is a PIDG R (Pre-Insulated Diamond Grip) terminal designed for electrical connections. It is suitable for wire sizes ranging from 22 to 16 AWG (American Wire Gauge). This terminal features a 5mm pin diameter, allowing for a secure and reliable connection. It is made from high-quality materials to ensure excellent conductivity and durability.The PIDG R 22-16 10 (5MM) terminal is pre-insulated, meaning it comes with a protective insulation sleeve. This insulation provides electrical insulation and prevents potential short circuits or electrical hazards.Whether used in industrial applications or automotive wiring, the TE Connectivity / AMP Brand part 130005 ensures a safe and efficient electrical connection. It is a trusted choice for professionals and DIY enthusiasts looking for a reliable terminal solution.
Product Highlights:
- Terminal Shape = Ring Tongue
- Receptacle Style = Straight
- Body Style = PIDG
- Barrel Type = Closed Barrel
- Wire/Cable Type = Regular Wire
Search Keywords:
130005
IN STOCK:
12,668
Can Ship immediately
On Order:
10,000
can ship 11/13/24
Minimum Order:
50
Factory Lead-Time
30 Weeks
Quantity
Unit Price
Ext. Price
50
$0.6821
$34.105
250
$0.4485
$112.125
1,000
$0.4392
$439.200
3,000
$0.4156
$1,246.800
5,000
$0.4020
$2,010.000
8,000
$0.4000
$3,200.000
10,000
$0.3815
$3,815.000
15,000
+
$0.3796
$5,694.000
