1-406525-1 by te connectivity / amp brand
DATA SHEET

1-406525-1

TE Connectivity / AMP Brand

Jack Modular Connector 8p8c (RJ45, Ethernet) 90° Angle (Right) Unshielded Cat5 .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-406525-1
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
608
Package Type:
Pack
Type:
RJ-45
Body Orientation:
Right Angle
Mounting:
Through Hole
Pitch:
2.04 mm
Gender:
F
Number of Contacts:
8
Maximum Voltage Rating:
150 VAC
Maximum Current Rating:
1.5/Contact A
Operating Temperature:
-40 to 80 °C
The 1-406525-1 is a 8P8C 1-port RJ45/CAT-5 right angle Modular Jack with gold-plated phosphor bronze contacts and high temperature thermoplastic housing. It is designed for direct mounting on PC boards, ease of soldering and board cleaning. Solder termination 150VAC Maximum voltage rating 750 Mating cycles durability UL94V-0 Flammability rating Number of Positions/Contacts 8p8c (RJ45, Ethernet) Number of Ports 1 Number of Rows 1 Mounting Type Through Hole Orientation 90° Angle (Right) Termination Solder Shielding Unshielded Ratings Cat5 Features Board Guide LED Color Does Not Contain LED Tab Direction Up Contact Material Phosphor Bronze Contact Finish Gold Applications Computers & Computer Peripherals
Product Highlights:
  • Jack
  • Single Port Configuration
  • 1 x 1 Jack Configuration
  • Jack Type = RJ45
  • Number of Positions = 8
Search Keywords:
14065251
IN STOCK: 50,356
Can Ship immediately
Minimum Order:
10
Factory Lead-Time
9 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
10
$1.908
$19.080
100
$1.259
$125.900
250
$1.196
$299.000
608
$1.184
$719.872
1,216
$1.172
$1,425.152
3,040
$1.161
$3,529.440
5,472
$1.149
$6,287.328
7,904 +
$1.138
$8,994.752
Suppliers Standard Package
