1-480709-9 by te connectivity / amp brand
DATA SHEET

1-480709-9

TE Connectivity / AMP Brand

12P UMNL CAP HSG BLK .. see full description

RoHS Compliant
Bag Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-480709-9
RoHS:
Yes
HTS:
8538906000
COO:
US
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Package Type:
Bag
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Termination Method:
Crimp
Number of Contacts:
12
Maximum Voltage Rating:
600 VAC
Maximum Current Rating:
19/Contact A
Operating Temperature:
-55 to 125 °C
The TE Connectivity / AMP Brand part 1-480709-9 is a 12P UMNL Cap HSG in black color. This ultra-miniature cap housing is ideal for applications requiring a compact and reliable electrical connection. It features a secure locking mechanism to ensure a secure mating with compatible connectors. The black color adds a sleek and professional look to the overall design. With its durable construction and compact size, this cap housing is perfect for various industries such as automotive, industrial, and telecommunications.
Product Highlights:
  • Housing
  • Universal MATE-N-LOK Product Line
  • Row-to-Row Spacing = 6.35 mm
  • Matrix Contact Layout
  • 6.35 mm Centerline
Search Keywords:
14807099
IN STOCK: 4,058
Ships today, if you order in
Manufacturer Stock:
26,000   can ship 12/6/24
Minimum Order:
100
Factory Lead-Time
6 Weeks can ship 1/3/25
Enter Quantity
Quantity
Unit Price
Ext. Price
100
$0.3314
$33.140
500
$0.2597
$129.850
3,000
$0.2459
$737.700
5,000
$0.2420
$1,210.000
8,000
$0.2283
$1,826.400
25,000
$0.2166
$5,415.000
50,000 +
$0.2144
$10,720.000
