1-644752-5 by te connectivity / amp brand
DATA SHEET

1-644752-5

TE Connectivity / AMP Brand

15P MTA156 HDR ASSY SQ STR F/L .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-644752-5
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Pack
PCB Mount Retention:
Without
Connector & Housing Type:
Plug
Contact Base Material:
Copper Alloy
Number of Power Positions:
15
Mating Retention:
With
UL Flammability Rating:
UL 94V-0
Circuit Application:
Power
Housing Material:
Polyester - GF
Contact Layout:
Inline
Number of Positions:
15
Connector & Contact Terminates To:
Printed Circuit Board
Panel Mount Feature:
Without
Connector Mounting Type:
Board Mount
Packaging Method:
Package
Contact Retention Within Housing:
Without
Sealable:
No
Mating Retention Type:
Friction Lock
Contact Underplating Material:
Nickel
PCB Mount Orientation:
Vertical
PCB Contact Termination Area Plating Material:
Tin
Packaging Quantity:
1
Strain Relief:
Without
Glow Wire Rating:
Standard Part - Not Glow Wire
Contact Current Rating (Max):
7 A
PCB Mount Alignment:
Without
Number of Rows:
1
Rectangular Power Connector Type:
Header
Mating Alignment:
Without
Housing Color:
Natural
Connector System:
Wire-to-Board
UL Rating:
Recognized
Contact Mating Area Plating Material:
Tin
Operating Voltage:
600 VAC
Termination Method to Printed Circuit Board:
Through Hole - Solder
Contact Type:
Pin
Header Type:
Partially Shrouded
Centerline (Pitch):
.156 in, 3.96 mm
Mating Post Length:
.4 in, 10.16 mm
Termination Post & Tail Length:
.175 in, 4.45 mm
PCB Thickness (Recommended):
1.6 in, .06 mm
Operating Temperature Range:
-55 – 105 °C, -67 – 221 °F
Contact Mating Area Plating Material Thickness:
100 µin, 2.54 µm
Approved Standards:
UL E28476
Connector Height:
.525 in, 13.34 mm
Product Length:
2.34 in, 59.44 mm
Agency/Standard:
CSA , UL , VDE
PCB Contact Termination Area Plating Material Thickness:
100 µin, 2.54 µm
CSA Rating:
Certified , LR 7189
Contact Underplating Material Thickness:
1.27 µin, 50 µm
15P MTA156 HDR ASSY SQ STR F/L
Product Highlights:
  • Header
  • 15 Positions
  • Preloaded
  • Header Gender = Plug
  • Contact Gender = Pin
Search Keywords:
16447525
IN STOCK: 583
Can Ship immediately
Minimum Order:
25
Factory Lead-Time
13 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$1.870
$46.750
250
$1.311
$327.750
500
$1.199
$599.500
1,000
$1.075
$1,075.000
2,500
$1.040
$2,600.000
5,000
$1.029
$5,145.000
7,500
$1.019
$7,642.500
10,000 +
$1.009
$10,090.000
Suppliers Standard Package
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
