1-647402-2 by te connectivity / amp brand
DATA SHEET

1-647402-2

TE Connectivity / AMP Brand

12P SL156 HSG W/RMP&TABS,OVSZ .. see full description

RoHS Compliant
Pack Packaging
Accessories
Request Programming Quote
This product is backed by Master Electronics' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Product Attribute
Attribute Value Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-647402-2
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
12
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
10/Contact A
Operating Temperature:
-55 to 105 °C
The TE Connectivity / AMP Brand part 1-647402-2 is a 12-pin, polarized SL156 housing designed for use in multiple applications. This oversized housing provides ample space for mating connectors and features integrated ramps and tabs for easy insertion and removal. Its OVSZ designation indicates that it is specifically designed for oversized wire sizes, ensuring a secure and reliable connection. This housing is a versatile and reliable solution for various electrical and electronic projects.
Product Highlights:
  • SL-156 Housings
  • Number of Positions = 12
  • Mating Type = Receptacle
  • Wire-to-Board Application
  • 3.96 mm Contact Centerline Spacing
Search Keywords:
16474022
IN STOCK: 122
Ships today, if you order in
Minimum Order:
25
Factory Lead-Time
12 Weeks
Enter Quantity
Quantity
Unit Price
Ext. Price
25
$1.575
$39.375
250
$1.419
$354.750
500
$1.405
$702.500
1,000
$1.126
$1,126.000
2,500
$1.114
$2,785.000
5,000
$1.009
$5,045.000
7,500
$0.999
$7,492.500
10,000 +
$0.961
$9,610.000
Please Note: Item may be subject to tariff fee if shipping within the United States
Tools/3D Models
Request Free CAD Models
PDF 3D PDF
